Introduction
A single LLM agent has limitations: finite context windows, single perspective bias, and vulnerability to cascading errors. Multi-agent systems address these by distributing work across specialized agents that communicate, coordinate, and reach consensus. This article covers the architectural patterns for building effective multi-agent systems.
Agent Roles and Specialization
Each agent should have a narrow, defined role:
@dataclass
class AgentSpec:
name: str
role: str
system_prompt: str
tools: list[dict]
model: str
class Agent:
def init(self, spec: AgentSpec, llm_fn):
self.spec = spec
self.llm = llm_fn
self.message_history = [{"role": "system", "content": spec.system_prompt}]
async def process(self, task: str, context: str = "") -> str:
messages = self.message_history + [{"role": "user", "content": f"{context}\n\nTask: {task}"}]
response = self.llm(messages, tools=self.spec.tools)
self.message_history.append({"role": "assistant", "content": response})
return response
Define specialized agents
researcher = Agent(AgentSpec(
name="Researcher",
role="Information retrieval and fact-checking",
system_prompt="You are a research specialist. Find accurate information and verify facts. Cite all sources.",
tools=[search_tool, web_scrape_tool],
model="claude-sonnet-4-20260512",
))
writer = Agent(AgentSpec(
name="Writer",
role="Content creation and editing",
system_prompt="You are a technical writer. Produce clear, well-structured content. Adapt tone to the audience.",
tools=[grammar_check_tool, style_guide_tool],
model="claude-sonnet-4-20260512",
))
critic = Agent(AgentSpec(
name="Critic",
role="Quality assurance and review",
system_prompt="You are a critical reviewer. Find errors, inconsistencies, and areas for improvement. Be thorough.",
tools=[],
model="claude-opus-4-20260512", # Stronger model for evaluation
))
Communication Protocols
Agents communicate through structured messages:
from enum import Enum
from datetime import datetime
class MessageType(Enum):
TASK = "task"
RESULT = "result"
QUERY = "query"
RESPONSE = "response"
FEEDBACK = "feedback"
COORDINATION = "coordination"
@dataclass
class AgentMessage:
id: str
sender: str
recipients: list[str]
type: MessageType
content: str
metadata: dict = None
timestamp: str = None
def post_init(self):
if self.timestamp is None:
self.timestamp = datetime.now().isoformat()
class MessageBus:
def init(self):
self.queues: dict[str, list[AgentMessage]] = {}
self.broadcast_log: list[AgentMessage] = []
def send(self, message: AgentMessage):
for recipient in message.recipients:
if recipient not in self.queues:
self.queues[recipient] = []
self.queues[recipient].append(message)
if not message.recipients:
self.broadcast_log.append(message)
def receive(self, agent_name: str) -> list[AgentMessage]:
return self.queues.pop(agent_name, [])
def broadcast(self, message: AgentMessage):
for agent in self.queues:
self.queues[agent].append(message)
self.broadcast_log.append(message)
Orchestration Patterns
Sequential Handoff
One agent passes results to the next in a pipeline:
class SequentialOrchestrator:
def init(self, agents: list[Agent], bus: MessageBus):
self.agents = agents
self.bus = bus
async def run(self, initial_task: str) -> str:
current_output = initial_task
for i, agent in enumerate(self.agents):
result = await agent.process(current_output)
current_output = result
if i < len(self.agents) - 1:
self.bus.send(AgentMessage(
id=f"handoff_{i}",
sender=agent.spec.name,
recipients=[self.agents[i+1].spec.name],
type=MessageType.TASK,
content=result,
))
return current_output
Debate and Consensus
Multiple agents work on the same problem and then converge:
class DebateOrchestrator:
def init(self, agents: list[Agent], rounds: int = 3):
self.agents = agents
self.rounds = rounds
async def debate(self, problem: str) -> str:
positions = {a.spec.name: await a.process(problem) for a in self.agents}
for round_num in range(self.rounds):
Share positions
summary = "\n".join(f"{name}: {pos}" for name, pos in positions.items())
Each agent critiques and refines
new_positions = {}
for agent in self.agents:
critique = await agent.process(
f"Round {round_num + 1}. Review these positions and refine your own:\n{summary}",
context=f"Your previous position: {positions[agent.spec.name]}"
)
new_positions[agent.spec.name] = critique
positions = new_positions
Final consensus
consensus_agent = self.agents[0]
summary = "\n".join(f"{name}: {pos}" for name, pos in positions.items())
consensus = await consensus_agent.process(
f"Based on all perspectives, produce a final consensus answer:\n{summary}"
)
return consensus
Manager-Worker Pattern
A manager agent decomposes tasks and delegates to workers:
class ManagerWorkerOrchestrator:
def init(self, manager: Agent, workers: list[Agent], bus: MessageBus):
self.manager = manager
self.workers = workers
self.bus = bus
async def run(self, task: str) -> str:
Manager creates a plan
plan = await self.manager.process(f"Decompose this task into sub-tasks and assign to workers: {task}")
sub_tasks = self._parse_plan(plan)
Distribute to workers
worker_futures = []
for sub_task in sub_tasks:
worker = self._select_worker(sub_task)
future = worker.process(sub_task["description"])
worker_futures.append(future)
Collect results
results = await asyncio.gather(*worker_futures)
Manager synthesizes final output
results_text = "\n".join(f"{st['id']}: {r}" for st, r in zip(sub_tasks, results))
final = await self.manager.process(
f"Synthesize these results into a coherent output:\n{results_text}",
context=f"Original task: {task}"
)
return final
def _select_worker(self, sub_task: dict) -> Agent:
skill = sub_task.get("required_skill", "general")
for worker in self.workers:
if skill in worker.spec.role.lower():
return worker
return self.workers[0]
Consensus with Voting
When agents disagree, a voting mechanism resolves conflicts:
def weighted_vote(proposals: list[dict], agent_weights: dict[str, float]) -> dict:
"""Weighted voting: each agent's vote is weighted by its reliability."""
vote_counts = {}
for proposal in proposals:
key = proposal["solution"]
weight = agent_weights.get(proposal["agent"], 1.0)
vote_counts[key] = vote_counts.get(key, 0) + weight
winner = max(vote_counts, key=vote_counts.get)
return {"winner": winner, "confidence": vote_counts[winner] / sum(vote_counts.values())}
Conclusion
Multi-agent systems distribute intelligence across specialized agents. Sequential handoff is suitable for linear pipelines. Debate and consensus produces higher-quality answers by challenging assumptions. Manager-worker scales to complex tasks by decomposing and delegating. Choose your coordination pattern based on the task: sequential for well-defined steps, debate for decisions requiring multiple perspectives, and manager-worker for complex projects with parallelizable sub-tasks.
