Introduction
Redis and Memcached are the two most widely used in-memory data stores, but they serve different purposes despite overlapping use cases. Memcached is a purpose-built cache; Redis is a versatile data structure server that happens to excel at caching. Choosing between them requires understanding their architectural differences and the specific requirements of your application.
Data Structure Support
Redis: Rich Data Types
Redis supports a wide range of data structures beyond simple key-value pairs:
import redis.asyncio as redis
r = redis.Redis(host='localhost', port=6379, decode_responses=True)
Strings (basic key-value)
await r.set('user:1000:name', 'Alice')
name = await r.get('user:1000:name')
Lists (ordered collection, great for queues)
await r.lpush('notifications:queue', 'email_1', 'email_2')
notification = await r.brpop('notifications:queue', timeout=5)
Sets (unique members, set operations)
await r.sadd('user:1000:roles', 'admin', 'editor', 'viewer')
await r.sadd('user:1001:roles', 'editor', 'viewer')
common_roles = await r.sinter('user:1000:roles', 'user:1001:roles')
Returns: {'editor', 'viewer'}
Sorted Sets (leaderboards, rate limiting)
await r.zadd('leaderboard:weekly', {'user:1000': 1500, 'user:1001': 2300})
top_players = await r.zrevrange('leaderboard:weekly', 0, 9, withscores=True)
Hashes (objects)
await r.hset('product:500', mapping={
'name': 'Widget',
'price': 29.99,
'stock': 100,
})
product = await r.hgetall('product:500')
Bitmaps (analytics, feature flags)
await r.setbit('active:users:2026-05-12', user_id=1000, value=1)
daily_active = await r.bitcount('active:users:2026-05-12')
Streams (event log, message queue)
await r.xadd('order:events', {'order_id': '123', 'status': 'created'})
events = await r.xread({'order:events': '0'}, count=10)
Memcached: Simple Key-Value
Memcached provides a minimal key-value API:
import pymemcache
client = pymemcache.Client(('localhost', 11211))
Basic get/set
client.set('user:1000:profile', profile_data, expire=3600)
profile = client.get('user:1000:profile')
Multi-get for batch operations
users = client.get_multi([
'user:1000:profile',
'user:1001:profile',
'user:1002:profile',
])
Atomic operations
client.add('lock:payment:123', 'locked', expire=30) # Only if not exists
client.replace('user:1000:profile', updated_profile) # Only if exists
client.append('log:buffer', 'new entry\n') # Append to existing value
client.prepend('log:buffer', 'header\n') # Prepend
Increment/Decrement
client.set('counter:api:day', '0')
client.incr('counter:api:day', 1)
Persistence and Durability
| Feature | Redis | Memcached |
|---|---|---|
| Persistence | RDB snapshots, AOF logs | None (ephemeral) |
| Recovery | Automatic on restart | All data lost |
| Replication | Master-replica, sentinel, cluster | No replication |
| Durability modes | fsync policies (always, every sec, no) | N/A |
Redis persistence configuration:
redis.conf
RDB snapshot (point-in-time)
save 900 1 # Save if 1 key changed in 900 seconds
save 300 10 # Save if 10 keys changed in 300 seconds
save 60 10000 # Save if 10000 keys changed in 60 seconds
AOF (append-only log)
appendonly yes
appendfsync everysec # fsync every second
auto-aof-rewrite-percentage 100
auto-aof-rewrite-min-size 64mb
Hybrid persistence (Redis 7+)
aof-use-rdb-preamble yes # RDB prefix for faster loading
Memory Efficiency and Eviction
Memcached: Slab Allocation
Memcached uses slab allocation to minimize fragmentation:
Memcached slab configuration
Memory is divided into slabs of various chunk sizes
Items are stored in the smallest slab that fits
stats = client.stats()
STAT slab_reassign_rescues 0
STAT slab_reassign_evictions_nomem 0
STAT slab_reassign_inline_reclaim 0
STAT slab_reassign_busy_items 0
Eviction: LRU only
client.set('key', 'value', expire=0, noreply=False)
Redis: Multiple Eviction Policies
redis.conf eviction policies
maxmemory 2gb
maxmemory-policy allkeys-lru # Evict least recently used keys
Available policies:
noeviction: Return errors on writes when memory full
allkeys-lru: Evict LRU keys (most common)
allkeys-lfu: Evict least frequently used
volatile-lru: Evict LRU among keys with TTL
volatile-lfu: Evict LFU among keys with TTL
allkeys-random: Evict random keys
volatile-random: Evict random keys with TTL
volatile-ttl: Evict keys with shortest TTL
Memory overhead comparison:
Redis: ~50 bytes overhead per key + value size
Example: 1M keys with 100-byte values
overhead_redis = 1_000_000 * (50 + 100) # ~150MB
Memcached: ~56 bytes overhead per key + value size + slab fragmentation
Example: 1M keys with 100-byte values
overhead_memcached = 1_000_000 * (56 + 100) # ~156MB + ~10% fragmentation
Clustering and High Availability
Redis Cluster
redis-cluster.conf (per node)
port 7000
cluster-enabled yes
cluster-config-file nodes.conf
cluster-node-timeout 5000
appendonly yes
3 master, 3 replica (production minimum)
Redis Cluster client
from redis.cluster import RedisCluster
rc = RedisCluster(
startup_nodes=[
{"host": "127.0.0.1", "port": "7000"},
{"host": "127.0.0.1", "port": "7001"},
{"host": "127.0.0.1", "port": "7002"},
],
decode_responses=True,
)
Automatic sharding: keys are distributed across 16384 slots
slot = CRC16(key) % 16384
await rc.set("user:1000:session", session_data)
await rc.get("user:1000:session")
Cross-slot operations require tags
await rc.set("{users}:1000", "alice")
await rc.set("{users}:1001", "bob")
users = await rc.mget("{users}:1000", "{users}:1001")
Memcached: No Built-in Clustering
Memcached has no built-in clustering. Sharding is implemented at the client level:
from pymemcache.client.hash import HashClient
Client-side consistent hashing
client = HashClient([
('memcached-1', 11211),
('memcached-2', 11211),
('memcached-3', 11211),
], use_pooling=True)
Consistent hashing minimizes cache misses when nodes change
client.set("key", "value")
result = client.get("key")
Use Case Comparison
| Use Case | Redis | Memcached |
|---|---|---|
| Simple key-value cache | Good (with persistence overhead) | Excellent |
| Session store | Excellent (built-in TTL, persistence) | Requires external persistence |
| Rate limiting | Excellent (sorted sets + atomic incr) | Basic (atomic incr only) |
| Message queue | Built-in (lists, streams, pub/sub) | No support |
| Leaderboards | Built-in (sorted sets) | No support |
| Geospatial queries | Yes (GEO commands) | No |
| Full-text search | Yes (RediSearch module) | No |
| Time-series data | Yes (RedisTimeSeries module) | No |
When to Use Which
-
Use Memcached when you need a simple, fast, memory-only cache for database query results or computed data that can be regenerated. Memcached excels at its single purpose.
-
Use Redis when you need data structures beyond key-value, persistence, replication, or any advanced caching patterns like rate limiting, session stores, or leaderboards.
-
Use both when you want a two-tier caching strategy: Memcached for hot cache (regenerable) and Redis for persistent cache (session, counter) and non-cache workloads.
For most modern applications, Redis is the better default due to its versatility. Reserve Memcached for specific high-throughput caching scenarios where Redis's overhead and feature set are unnecessary.
