Database Design Patterns: Repository, Unit of Work, Query Objects, Table Inheritance
Design patterns provide reusable solutions to common database access problems. This article covers patterns that help decouple business logic from database access, manage transactions, and model inheritance.
Repository Pattern
The Repository pattern mediates between the domain model and the database, providing a collection-like interface for accessing domain objects.
Interface
from abc import ABC, abstractmethod
from typing import Optional, List
class UserRepository(ABC):
@abstractmethod
def find_by_id(self, user_id: int) -> Optional[dict]:
pass
@abstractmethod
def find_by_email(self, email: str) -> Optional[dict]:
pass
@abstractmethod
def save(self, user: dict) -> int:
pass
@abstractmethod
def delete(self, user_id: int) -> bool:
pass
Implementation
import psycopg2
from psycopg2.extras import RealDictCursor
class PostgresUserRepository(UserRepository):
def init(self, conn):
self.conn = conn
def find_by_id(self, user_id: int) -> Optional[dict]:
with self.conn.cursor(cursor_factory=RealDictCursor) as cur:
cur.execute(
"SELECT * FROM users WHERE id = %s",
(user_id,)
)
return cur.fetchone()
def find_by_email(self, email: str) -> Optional[dict]:
with self.conn.cursor(cursor_factory=RealDictCursor) as cur:
cur.execute(
"SELECT * FROM users WHERE email = %s",
(email,)
)
return cur.fetchone()
def save(self, user: dict) -> int:
with self.conn.cursor() as cur:
if 'id' in user:
cur.execute("""
UPDATE users SET email = %s, name = %s
WHERE id = %s RETURNING id
""", (user['email'], user['name'], user['id']))
else:
cur.execute("""
INSERT INTO users (email, name)
VALUES (%s, %s) RETURNING id
""", (user['email'], user['name']))
return cur.fetchone()[0]
def delete(self, user_id: int) -> bool:
with self.conn.cursor() as cur:
cur.execute(
"DELETE FROM users WHERE id = %s", (user_id,)
)
return cur.rowcount > 0
Benefits
-
Testability : Mock the repository interface for unit tests.
-
Encapsulation : SQL is contained within the repository.
-
Swappable : Change database implementation without changing business logic.
-
Query optimization : Changes are isolated to the repository.
Unit of Work Pattern
Unit of Work tracks changes to objects during a business transaction and writes them as a single unit:
class UnitOfWork:
def init(self, conn):
self.conn = conn
self.new_objects = []
self.dirty_objects = []
self.deleted_objects = []
self.repositories = {}
def register_new(self, obj):
self.new_objects.append(obj)
def register_dirty(self, obj):
if obj not in self.dirty_objects:
self.dirty_objects.append(obj)
def register_deleted(self, obj):
self.deleted_objects.append(obj)
def commit(self):
if not self.new_objects and not self.dirty_objects and not self.deleted_objects:
return
with self.conn:
for obj in self.deleted_objects:
self._delete(obj)
for obj in self.dirty_objects:
self._update(obj)
for obj in self.new_objects:
self._insert(obj)
self.new_objects.clear()
self.dirty_objects.clear()
self.deleted_objects.clear()
def _insert(self, obj):
repo = self._get_repo(type(obj))
repo.save(obj)
def _update(self, obj):
repo = self._get_repo(type(obj))
repo.save(obj)
def _delete(self, obj):
repo = self._get_repo(type(obj))
repo.delete(obj.id)
def _get_repo(self, obj_type):
Repository registry determines which repository maps to which type
pass
Usage
def create_order(user_id, items):
uow = UnitOfWork(connection)
user_repo = UserRepository(uow)
order_repo = OrderRepository(uow)
user = user_repo.find_by_id(user_id)
user['last_order_date'] = datetime.utcnow()
uow.register_dirty(user)
order = {'user_id': user_id, 'items': items, 'total': calculate_total(items)}
uow.register_new(order)
uow.commit() # All changes in one transaction
Query Object Pattern
Query Objects encapsulate database queries as reusable objects:
from dataclasses import dataclass
from typing import Optional, List
@dataclass
class OrderQuery:
user_id: Optional[int] = None
status: Optional[str] = None
min_total: Optional[float] = None
max_total: Optional[float] = None
created_after: Optional[str] = None
created_before: Optional[str] = None
sort_by: str = 'created_at'
sort_order: str = 'DESC'
limit: int = 100
offset: int = 0
def to_sql(self) -> tuple:
conditions = []
params = []
param_index = 1
if self.user_id is not None:
conditions.append(f"user_id = ${param_index}")
params.append(self.user_id)
param_index += 1
if self.status is not None:
conditions.append(f"status = ${param_index}")
params.append(self.status)
param_index += 1
if self.min_total is not None:
conditions.append(f"total >= ${param_index}")
params.append(self.min_total)
param_index += 1
if self.max_total is not None:
conditions.append(f"total <= ${param_index}")
params.append(self.max_total)
param_index += 1
if self.created_after is not None:
conditions.append(f"created_at >= ${param_index}")
params.append(self.created_after)
param_index += 1
if self.created_before is not None:
conditions.append(f"created_at <= ${param_index}")
params.append(self.created_before)
param_index += 1
where_clause = " AND ".join(conditions) if conditions else "TRUE"
sql = f"""
SELECT * FROM orders
WHERE {where_clause}
ORDER BY {self.sort_by} {self.sort_order}
LIMIT ${param_index} OFFSET ${param_index + 1}
"""
params.extend([self.limit, self.offset])
return sql, params
class OrderRepository:
def init(self, conn):
self.conn = conn
def find_by_query(self, query: OrderQuery) -> List[dict]:
sql, params = query.to_sql()
with self.conn.cursor(cursor_factory=RealDictCursor) as cur:
cur.execute(sql, params)
return cur.fetchall()
Table Inheritance Patterns
Single Table Inheritance (STI)
All types in one table with a type discriminator column:
CREATE TABLE content_items (
id BIGSERIAL PRIMARY KEY,
type TEXT NOT NULL, -- 'article', 'video', 'podcast'
title TEXT NOT NULL,
body TEXT, -- articles only
video_url TEXT, -- videos only
audio_url TEXT, -- podcasts only
duration_seconds INTEGER, -- videos and podcasts only
created_at TIMESTAMPTZ DEFAULT NOW()
);
CREATE INDEX idx_content_type ON content_items (type);
Pros : Simple queries, no joins. Cons : Many nullable columns, wasted space.
Class Table Inheritance (CTI)
One table for base type, separate tables for subtypes:
CREATE TABLE content_items (
id BIGSERIAL PRIMARY KEY,
title TEXT NOT NULL,
created_at TIMESTAMPTZ DEFAULT NOW()
);
CREATE TABLE articles (
id BIGINT PRIMARY KEY REFERENCES content_items(id),
body TEXT NOT NULL
);
CREATE TABLE videos (
id BIGINT PRIMARY KEY REFERENCES content_items(id),
video_url TEXT NOT NULL,
duration_seconds INTEGER
);
Pros : No wasted space, clean schema. Cons : Requires JOIN to read full object.
class ContentRepository:
def find_article(self, article_id: int):
cur.execute("""
SELECT c.*, a.body
FROM content_items c
JOIN articles a ON a.id = c.id
WHERE c.id = %s
""", (article_id,))
Concrete Table Inheritance
Each subtype has its own complete table:
CREATE TABLE articles (
id BIGSERIAL PRIMARY KEY,
title TEXT NOT NULL,
body TEXT NOT NULL,
created_at TIMESTAMPTZ DEFAULT NOW()
);
CREATE TABLE videos (
id BIGSERIAL PRIMARY KEY,
title TEXT NOT NULL,
video_url TEXT NOT NULL,
duration_seconds INTEGER,
created_at TIMESTAMPTZ DEFAULT NOW()
);
Pros : No joins, no nullable columns. Cons : Duplicated columns, hard to query across types.
When to Use Each
| Pattern | Use Case | |---------|----------| | Single Table | Few subtypes, similar columns, simple queries | | Class Table | Many shared columns, many different columns | | Concrete Table | Completely different behavior per type, no cross-type queries |
Choosing the Right Pattern
-
Use Repository for most CRUD-heavy applications (standard web apps).
-
Use Unit of Work when transactions span multiple objects (order processing, accounting).
-
Use Query Objects when queries have many optional parameters (reports, search APIs).
-
Use Table Inheritance based on how your domain model maps to data.
These patterns are not prescriptive rules but tools. Use them when they simplify your code; do not force them into a simple application that would be better served by direct SQL or a lightweight ORM.
