API Rate Limiting Implementation

Why Rate Limiting Matters

Rate limiting protects APIs from abuse, DoS attacks, and unintentional overload. It ensures fair usage and maintains service quality for all consumers.

Rate Limiting Algorithms

Token Bucket

The most popular algorithm, allowing bursts while maintaining average limits:

import time

import threading

class TokenBucket:

def init(self, rate, capacity):

self.rate = rate # Tokens per second

self.capacity = capacity

self.tokens = capacity

self.last_refill = time.monotonic()

self.lock = threading.Lock()

def consume(self, tokens=1):

with self.lock:

self._refill()

if self.tokens >= tokens:

self.tokens -= tokens

return True

return False

def _refill(self):

now = time.monotonic()

elapsed = now - self.last_refill

self.tokens = min(self.capacity,

self.tokens + elapsed * self.rate)

self.last_refill = now

Usage

bucket = TokenBucket(rate=10, capacity=20) # 10 req/s, burst 20

if bucket.consume():

process_request()

else:

return "429 Too Many Requests"

Sliding Window Log

More precise but memory-intensive:

from collections import deque

import time

class SlidingWindowLog:

def init(self, window_size=60, max_requests=100):

self.window_size = window_size

self.max_requests = max_requests

self.log = deque()

def allow_request(self):

now = time.time()

Remove expired entries

while self.log and self.log[0] <= now - self.window_size:

self.log.popleft()

if len(self.log) < self.max_requests:

self.log.append(now)

return True

return False

Rate Limiting Headers

Return standard headers for client feedback:

def rate_limit_response(allowed, limit, remaining, reset):

if allowed:

return {

"X-RateLimit-Limit": str(limit),

"X-RateLimit-Remaining": str(remaining),

"X-RateLimit-Reset": str(reset)

}

else:

return {

"X-RateLimit-Limit": str(limit),

"X-RateLimit-Remaining": "0",

"Retry-After": str(reset - int(time.time()))

}, 429

Distributed Redis Implementation

For multi-server deployments:

import redis

import time

class RedisSlidingWindow:

def init(self, redis_client):

self.redis = redis_client

def is_allowed(self, key, max_requests=100, window_seconds=60):

now = int(time.time() * 1000)

window_start = now - (window_seconds * 1000)

pipeline = self.redis.pipeline()

pipeline.zremrangebyscore(key, 0, window_start)

pipeline.zcard(key)

pipeline.zadd(key, {str(now): now})

pipeline.expire(key, window_seconds * 2)

, count, , _ = pipeline.execute()

return count < max_requests

Middleware Implementation

const rateLimit = require("express-rate-limit");

const apiLimiter = rateLimit({

windowMs: 15 * 60 * 1000,

max: 100,

standardHeaders: true,

legacyHeaders: false,

message: { error: "Too many requests, please try again later." },

keyGenerator: (req) => req.user?.id || req.ip,

skip: (req) => req.headers["x-internal"] === process.env.INTERNAL_TOKEN

});

app.use("/api/", apiLimiter);

Conclusion

Choose the right rate limiting algorithm for your use case. Token bucket works well for most APIs. Use Redis for distributed rate limiting across multiple servers. Always return clear rate limit headers so clients can self-regulate. Monitor rate limit hit rates to tune thresholds over time.
