Introduction
Performance profiling identifies where your application spends its time — CPU, memory, I/O, or blocking. Without profiling, optimization is guesswork. This article covers four profiling approaches: perf for system-level Linux profiling, flamegraphs for visualization, py-spy for Python without code changes, and pprof for Go applications.
perf (Linux Profiler)
The built-in Linux profiler for CPU, hardware events, and tracepoints:
CPU profiling
perf record -F 99 -g ./myapp # Sample at 99Hz with call graphs
perf record -F 99 -p PID -g --sleep 30 # Profile running process for 30s
perf report --stdio # Text report
perf report -g graph # Call graph report
Common events
perf stat ./myapp # Execution statistics
perf stat -e cache-misses ./myapp # Cache miss analysis
perf stat -e branch-misses ./myapp # Branch prediction
perf stat -e context-switches -p PID # Context switch monitoring
Hardware event sampling
perf record -e cycles -F 99 -a -g --sleep 10 # System-wide CPU sampling
Tracepoints
perf record -e sched:sched_switch -a -g # Context switch tracing
perf record -e syscalls:sys_enter_write -a # Write syscall tracing
Top-like live view
perf top -p PID
perf top -e cache-misses
Generate flamegraph data
perf script > out.perf
Key metrics : cycles for CPU time, cache-misses for memory bottleneck detection, context-switches for contention issues.
Flamegraphs
Brendan Gregg's visualization for profiler output:
Install FlameGraph tools
git clone https://github.com/brendangregg/FlameGraph
Generate flamegraph from perf data
perf script | ./FlameGraph/stackcollapse-perf.pl > out.folded
./FlameGraph/flamegraph.pl out.folded > flamegraph.svg
Generate differential flamegraph (before/after)
After optimization:
perf script | ./FlameGraph/stackcollapse-perf.pl > optimized.folded
./FlameGraph/difffolded.pl before.folded optimized.folded | ./FlameGraph/flamegraph.pl > diff.svg
Reading flamegraphs : The x-axis shows stack profile population (not time). Each rectangle is a function call; wider rectangles mean more CPU time. The y-axis is stack depth. Look for wide top rectangles — those are the hot functions.
For other languages :
JavaScript (Node.js)
node --perf-basic-prof app.js
perf script | ./FlameGraph/stackcollapse-perf.pl > out.folded
Python with py-spy
py-spy record -o profile.svg --pid $PID
Go with pprof
go tool pprof -http=:8080 http://localhost:6060/debug/pprof/profile?seconds=30
py-spy
Sampling profiler for Python without modifying code:
Installation
pip install py-spy
Profile a running process
py-spy record -o profile.svg --pid 12345
py-spy record -o profile.svg -- python myapp.py
Top-like live view
py-spy top --pid 12345
Dump current stack traces
py-spy dump --pid 12345
Profile specific duration
py-spy record -o profile.svg --pid 12345 --duration 30
With subprocesses
py-spy record -o profile.svg -- python myapp.py --subprocesses
Native frames
py-spy record --native -o profile.svg --pid 12345
Save raw data for later analysis
py-spy record -o profile.raw --pid 12345 --format raw
Key advantages : No code changes required, works with running processes, safe for production (read-only), native code frame support.
pprof (Go)
Go's built-in profiling tool:
package main
import (
"net/http"
_ "net/http/pprof"
)
func main() {
// Start pprof HTTP server
go func() {
http.ListenAndServe("localhost:6060", nil)
}()
// Your application code...
}
Collect profiles
go tool pprof http://localhost:6060/debug/pprof/profile?seconds=30 # CPU
go tool pprof http://localhost:6060/debug/pprof/heap # Memory
go tool pprof http://localhost:6060/debug/pprof/goroutine # Goroutines
go tool pprof http://localhost:6060/debug/pprof/block # Blocking
go tool pprof http://localhost:6060/debug/pprof/mutex # Mutex contention
Interactive exploration
go tool pprof cpu.pprof
(pprof) top10 # Top 10 functions
(pprof) list myFunc # Source with line-level timing
(pprof) web # Open in browser (requires graphviz)
(pprof) pdf # Generate PDF
(pprof) peek myFunc # Caller/callee view
Web interface
go tool pprof -http=:8080 cpu.pprof
Allocations profiling
go tool pprof -http=:8080 http://localhost:6060/debug/pprof/allocs
Compare profiles
go tool pprof -http=:8080 -diff_base=before.pprof after.pprof
Profiling Workflow
1\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Identify the problem (slow response, high CPU, OOM)
2\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Profile without optimization
perf record -F 99 -p $(pgrep myapp) -g --sleep 30
3\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Generate flamegraph
perf script | stackcollapse-perf.pl | flamegraph.pl > before.svg
4\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Make optimization
5\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Profile again with same parameters
perf record -F 99 -p $(pgrep myapp) -g --sleep 30
perf script | stackcollapse-perf.pl | flamegraph.pl > after.svg
6\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\. Create differential flamegraph
./difffolded.pl before.folded after.folded | flamegraph.pl > diff.svg
Comparison
| Tool | Language | Overhead | Best For |
|------|----------|----------|----------|
| perf | Any (system) | Low | CPU, cache misses, syscalls |
| flamegraphs | Any (visualization) | None | Visual hotspot identification |
| py-spy | Python | Very low | Production Python profiling |
| pprof | Go | Low | Go CPU, memory, goroutines |
| FlameGraph | Any (post-processing) | None | Comparative analysis |
Recommendations
-
Initial investigation : Use
perf topto quickly identify CPU hotspots. -
Detailed analysis : Collect perf data and generate flamegraphs for visual hotspot identification.
-
Python profiling : Use py-spy for production-safe sampling without code changes.
-
Go profiling : Use pprof with its web interface for interactive exploration.
-
Comparison : Use differential flamegraphs to verify optimization impact.
Profiling is an iterative process: identify hotspots, form a hypothesis, make a change, and re-profile to verify improvement. Flamegraphs make this loop faster by providing immediate visual feedback on where time is spent.
